250mm 300mm electroplated grinding disc for bead milling and polishing

JR012

Delivery:

FOB

minimum order:

10 pieces

Supply Ability:

10000pieces / Month

Country of Origin:

Guangzhou

Quantity:

USD20.00 - USD200.00 / pieces

Contact Now

add to cart

Grit:60/80
Grit:120
Grit:80
Grit:100
Grit:150
Grit:220
Wheel Type:Straight Grinding Wheels
Place of Origin:CN
Shape:Flat-Shaped
Bonding Agent:electroplated
Brand Name:JR
Model Number:1A2
Viscosity:as required
Product name:250mm 300mm electroplated grinding disc for bead milling and polishing
Abrasive:diamond
Regular Size:6inch, 8inch, 10inch
Thickness:can be customized
bond:electroplated
Hardness:as required
Body Material:Aluminum or Steel
Grain:80#, 120#, 240#, 600# etc
Usage:grinding, sharpening, polishing
work piece:gemstone, lapidary etc

Product Description

Diamond grinding discs are an important tool for bead forming. The diamond disc simplifies the process and improves the processing efficiency. A worker can operate several bead machines at the same time, which reduces the processing cost of mass production and it is suitable for processing materials of any hardness, such as jade, agate, crystal, jade, tree fossils, Beading operation of amber wax, ivory bone, hardwood and other materials.

Specification:

Grinding disc diameter: 250/300mm

Bead size: 3/4/5/6/7/8/9/10/12/14/16/18/20mm

Diamond particle size: 80# (can be customized according to customer needs)

Customers can choose whether to use large or small discs depending on the weight, hardness and size of the processed materials.
The small-sized grinding disc has better smoothness than the large-sized grinding disc during operation, further improving the
yield of the beads.

Products Show

Features:

1) Product performance: diamond abrasive is the main component of diamond grinding disc. The diamond quality will be affected the quantity and quality of beads. Our factory uses high-quality diamond. The grinding disc is processed by precision lathe finishing machine and professional electroplating technology. The grinding disc is wear-resistant, and the rounded beads have good roundness and high accuracy.

2) Processing range: can process 3MM-22MM beads.

3) High-efficiency production: It can be milled from one hundred to one thousand at a time. The grinding time is determined as per
the hardness of the processing materials and the size.

4) Matching machine: small chamfering machine, large automatic chamfering machine.

How to use the diamond bead milling disc?
Put the beads into the middle plate (15 grooves are also needed for the 8MM), each one empty position for a bead. And then start the grinding machine and adjust the time, it will mechanically stop it automatically after grinding.
