Bond Type
2023-03-13
Bond type
Metal bond
Sintering with metal powder and Diamond or CBN abrasive. Abrasive is strong-retention, heat-resistant, superior wear resistance.Used for easily deformed job or job required higher grinding performance, especially in grinding and cutting for glasses, lens, iron oxides, ceramics.And the conditions are both dry grinding and wet grinding.
Resin bond
Formed condensed of synthetic resin. Compared with metal bond,the retention of resin bond is lower,but grinding ability is highlighted and the abrasive is flowable. The feature is high grinding with low loading. Dry grinding and wet grinding are both excellent with wide use. Most suitable for grinding carbide, high speed steel and other materials.
Vitrified bond
Formed condensed of substances such as glass and magnetic. Abrasive is strong-retention, heat-resistant. Compared with metal bond, the grinding ability is higher, Compared with resin bond, the service life is longer. Most suitable for PCD、 PCBN、natural gemstone and other materials.
Electroplating bond
Fix the Diamond or CBN abrasive by method of electroplating. Suitable for the grinding job that is easily causing loading and deformation. Also suitable for the job with high requirement on grinding.
Hybrid bond
'Hybrid' bond which is a special grit that will grind both steels and carbides (Typically used on parts that require grinding of carbide and steel at the same time).
Metal bond
Sintering with metal powder and Diamond or CBN abrasive. Abrasive is strong-retention, heat-resistant, superior wear resistance.Used for easily deformed job or job required higher grinding performance, especially in grinding and cutting for glasses, lens, iron oxides, ceramics.And the conditions are both dry grinding and wet grinding.
Resin bond
Formed condensed of synthetic resin. Compared with metal bond,the retention of resin bond is lower,but grinding ability is highlighted and the abrasive is flowable. The feature is high grinding with low loading. Dry grinding and wet grinding are both excellent with wide use. Most suitable for grinding carbide, high speed steel and other materials.
Vitrified bond
Formed condensed of substances such as glass and magnetic. Abrasive is strong-retention, heat-resistant. Compared with metal bond, the grinding ability is higher, Compared with resin bond, the service life is longer. Most suitable for PCD、 PCBN、natural gemstone and other materials.
Electroplating bond
Fix the Diamond or CBN abrasive by method of electroplating. Suitable for the grinding job that is easily causing loading and deformation. Also suitable for the job with high requirement on grinding.
Hybrid bond
'Hybrid' bond which is a special grit that will grind both steels and carbides (Typically used on parts that require grinding of carbide and steel at the same time).
